    Automated And Customizable Sheet Metal Processing Machine For Kitchen Sink Production

    Ask Lasest Price
    Brand Name : Star Power
    Model Number : 63T-2500MM
    Certification : CU,ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100 Set/Sets per Month
    Delivery Time : 1 month
    • Product Details
    • Company Profile

    Automated And Customizable Sheet Metal Processing Machine For Kitchen Sink Production

    Automated and Customizable Sheet Metal Processing Machine for Kitchen Sink Production

    The sheet metal processing machine is a kind of equipment used for processing and shaping metal sheets.

    It usually has the following characteristics and functions:

    1.Cutting function: It can precisely cut the metal sheet according to the predetermined shape and size. Common cutting methods include laser cutting, plasma cutting, water jet cutting, etc.
    For example, a laser cutting machine can use a high-energy-density laser beam to instantly melt and vaporize the metal material to achieve high-precision and high-quality cutting.

    2.Stamping function: By applying pressure to the sheet through a mold, various shapes of holes, protrusions or depressions are formed.
    For instance, when manufacturing automotive parts, the stamping function can be used to punch out installation holes of specific shapes on the sheet metal.

    3.Bending function: It can bend the sheet into different angles and shapes to meet the requirements of product design.
    Like when making electrical enclosures, the sheet metal needs to be bent to form a three-dimensional structure.

    4.Welding function: Weld the cut and formed sheet metal components to make them a complete structure.
    For example, when manufacturing metal cabinets, the sheet metal of each part needs to be connected together through welding.

    In conclusion, the sheet metal processing machine plays an important role in many fields such as machinery manufacturing, automotive manufacturing, electronic equipment, aerospace, etc., and can process metal sheets into various complex shapes and high-precision parts and products.

    Specifications:


    Process termProcess introductionmachineMachine sizefloor spacepower
    (Kw)
    Length(m)Width(m)
    Process 1Steel Coil Laser cuttingLaser cutter line12000x2600x1950mm172.645
    Process 2Sheet welding for Saving MaterialStraight Seam Welding Machine1400x1100x2000mm1.41.10.4
    Process 3Sheet Grinding for Saving MaterialSheet Grinding Machine2250x1550x1800mm2.31.63.2
    Process 4Punching of water holeDeep throat Press machine/J21S-40T1500x1200x2000mm1.51.24
    Process 5Punching for PrebendingDeep throat press machine/J21S-63T1700x1400x2200mm1.71.44
    Process 6Press the water lineBending machine/30T-1600MM2600x1400x2000mm2.61.43
    Process 7Bending of the sink baseBending machine/63T-2500MM2800X1700X2350MM2.81.75.5
    Process 8Press arc & bottom cornerTwo-In-One Integrated Rolling Seam&Corner Pressing Machine1300x750x2000mm1.30.752.3
    Process 9Welding for vertical seams and bottom cornerCNC Welding Special Machine1400x1100x2000mm1.41.10.4
    Process 10Round corner Of vertical seams grinding (Inside)Grinding Machine For Round corner Of vertical seams2550x850x2200mm2.60.852.3
    Process 11Repair the Panel's missing cornersCNC Welding Special Machine(for panel repair)1100x850x1450mm1.10.850.4
    Process 12CNC Welding For Panel's Inner EdgeMulti-Axis CNC Welding Special Machine
    (For panel's inner edge)
    1700x1400x1600mm1.71.41.3
    Process 13Grinding for the sink's panelGrinding machine (Abrasive belt type)2500x1400x1700mm2.51.43
    Process 14Grinding for the sink's panel(mirror surface)Grinding machine3000x1400x1700mm31.43
    Process 15Painting For Sink Bottom Back SideManual painting equipment2200X1800X1600mm2.21.84.5
    Process 16Drying after PaintingDrying Oven13000X1000X1600mm13130
    Total floor space(Includ spaced distance and transportation route):>65m(Length)x 10m(Width)

    Process flowEquipment nameSpecific machine name
    CuttingLaser cuttingCustomizable
    Seam and corner pressingSeam and corner pressing machineSeam pressing machine, Corner pressing machine, Integrated seam and corner pressing machine
    StampingStamping machinePunching of water hole,Punching of Prebending
    BendingBending machineBending to form the bowl shape,
    Press the water line
    WeldingWelding machineCNC fillet welding machine, CNC corner mending welding machine, seam welding machine, CNC planar welding machine,
    Press arc & bottom
    corner,
    Grinding and polishingGrinding and polishing machine
    Automatic Grinding for the
    sink's panel(Rough
    Polishing),Automatic Grinding for the
    sink's panel(Fine Polishing),
    Round corner Of vertical
    seams grinding (Inside)

    Advantages:


    Automated And Customizable Sheet Metal Processing Machine For Kitchen Sink ProductionAutomated And Customizable Sheet Metal Processing Machine For Kitchen Sink Production
